The wind power filter can effectively remove suspended solids, particles, etc. in the liquid. Large flow rate and small pressure loss. High residue load and long service life. Can withstand high filtration pressure. According to the nature of the liquid to be filtered, the wind power gearbox filter element has a variety of different materials to choose from, so that the filter element and the filtrate have good compatibility.
Utama prestasi:
1. Tinggi penapisan ketepatan, small pressure difference, large flow rate, large dirt holding capacity and long service life;
2. The filter pore size is small inside and large outside, which has a good deep filter effect;
3. The filter element is made of different materials to ensure various liquid filtration requirements and achieve the filtering effect. the
Utama teknikal prestasi petunjuk:
1. Filtration accuracy: 1μm, 5μm, 10μm, 20μm, 30μm, 50μm, 75μm, 100μm;
2. Luar diameter of filter element: φ60mm, φ65mm;
3. Inner diameter of filter element: φ28mm, φ30mm;
4. Polipropilena wayar-luka filter elements can be used for non-organic solutions such as water, acid and alkali, chemical solutions, etc., and the operating temperature is Less than or equal to 60 degree
5. The center rod of the absorbent cotton fiber filter element is made of stainless steel, which is used for organic solvents, water, oil, alkaline solutions, beverages, medicines, etc., and the operating temperature is 120 degree . the
6. Filter element length: 10″, 20″, 30″, 40″
7. Tinggi withstand voltage: Less than or equal to 0.5MPa; large pressure drop: 0.2MPa. the
8. Tinggi bekerja suhu: Polypropylene thread: polypropylene skeleton Less than or equal to 60 degree ; stainless steel skeleton Less than or equal to 80 degree . Absorbent cotton thread: stainless steel skeleton Less than or equal to 120 degree .
